Cylindrical Autoclave 16x36 120 liters

Get a Price/Quote

Product Details:

Product Type Cylindrical Autoclave 16x36 120 liters
Usage Laboratory
Color Silver
Material Stainless steel
Operate Method Automatic
Type Horizontal Cylindrical
Chamber Size 16x36 inches (120 liters)
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Cylindrical Autoclave 16x36 120 liters Price And Quantity

Minimum Order Quantity 1 Piece

Cylindrical Autoclave 16x36 120 liters Product Specifications

Outer Size 16x36 inches
Material Stainless steel
Recording Parameters Digital temperature and pressure recorder
Product Type Cylindrical Autoclave 16x36 120 liters
Design Pressure 2.2 kg/cm
Usage Laboratory
Door Type Manual swing type/single door
Valves High pressure safety, steam release, and air vent valves
Type Horizontal Cylindrical
Color Silver
Working Temperature 121C
Working Pressure 1.2-1.5 kg/cm
Temperature Scope Up to 134C
Net Weight Approx. 120 kg
Spraying Piping High-pressure stainless steel spray pipes
Chamber Size 16x36 inches (120 liters)
Compressed Air Required
Chamber Thickness 4-6 mm (Stainless steel grade 304/316)
Sterilizing Temperature 121C
Operate Method Automatic
Design Temperature 134C
Steam External steam source
Sterilization Time 15-30 minutes
Insulation High grade mineral wool/ceramic insulation
Power Consumption 3-6 kW (depends on model)
Spraying Mode Rotational spraying
Inner Trolley Removable Stainless Steel Trolley
Heat Uniform Uniform heat distribution by steam jacket
Outer Trolley Provided
Piping System SS316 piping with safety features

Cylindrical Autoclave 16x36 120 liters Trade Information

Delivery Time 7-10 Days

Product Description

Experience phenomenal sterilization power with the Cylindrical Autoclave 16x36 120 liters, now available at the lowest price on clearance! This dominant masterpiece features a microprocessor-based digital control system with an LED display for precise monitoring. Safety is ensured through pressure and temperature interlocks, automatic pressure release, and a reliable water level indicator. Its robust stainless steel construction, silicone gasket, and heavy-duty MS frame guarantee durability and airtight sealing. Shop now and master your laboratory processes with outstanding uniform heat distribution, CE and ISO compliance, and unrivaled efficiency. Ideal for importers, distributors, and service providers across India.

Exemplary Laboratory Sterilization Usage

The Cylindrical Autoclave 16x36 120 liters is engineered for intensive laboratory applications. As a horizontal cylindrical sterilizer, it is specifically designed for handling a wide array of scientific instruments and materials, ensuring thorough sterilization for research facilities, diagnostic centers, and medical laboratories. Its automatic operation and high-pressure performance make it indispensable for laboratories requiring consistent and reliable sterilization outcomes, supporting demanding research and healthcare environments.

Export Market, Supply Capacity, and Payment Procedures

Supplying to dominant global markets, our rate competitive Cylindrical Autoclave boasts a robust supply ability, facilitating order completion on schedule. Export distribution covers Europe, Asia, Africa, and the Americas, supporting regular purchase order protocols and flexible payment terms. We work closely with buyers to streamline processing and guarantee timely delivery, ensuring quick turnaround from order to fulfillment, backed by industry-leading service and technical support.

FAQs of Cylindrical Autoclave 16x36 120 liters:

Q: How does the microprocessor-based digital control enhance the autoclaves performance?

A: The microprocessor-based digital control ensures precise monitoring and regulation of temperature and pressure, delivering consistent and safe sterilization cycles. Its LED digital display provides real-time data for optimal operation, allowing users to fine-tune parameters for superior results.

Q: What safety features are included in the Cylindrical Autoclave 16x36?

A: This autoclave includes pressure and temperature interlocks, automatic pressure release mechanisms, high-pressure safety valves, and an air vent. These integrated features uphold operational safety and safeguard users during every use.

Q: When should the automatic pressure release function be used?

A: The automatic pressure release is engaged at the end of the sterilization cycle or if abnormal pressure levels are detected, ensuring safe decompression of the chamber and preventing potential hazards to operators.

Q: Where is the Cylindrical Autoclave 16x36 commonly used?

A: It is predominantly utilized in laboratories, medical research institutions, and clinical facilities, catering to rigorous sterilization requirements of scientific, pharmaceutical, and healthcare operations.

Q: What is the process for placing an order and what payment terms are available?

A: Orders can be initiated through a purchase order process, followed by confirmation and completion. Flexible payment terms are offered to buyers, including direct bank transfers and letters of credit, supporting streamlined transaction management.

Q: How does rotational spraying benefit chamber sterilization efficiency?

A: Rotational spraying via high-pressure stainless steel spray pipes ensures uniform distribution of steam, maximizing contact with all surfaces and guaranteeing effective and reliable sterilization throughout the chamber.
